Mobile Pallet Racking System

Product Description

System Type

Mechanically Assisted / Electrically Operated / Manual Push-Pull

• Designed to move on tracks for compact storage and high-density racking

Structure & Material

• Frame Material: High-grade cold-rolled steel (CRCA) / structural steel
• Finish: Powder-coated / epoxy painted for corrosion resistance
• Load Beams: Roll-formed or structural steel beams (box / step beams)

Load Capacity

• Per Rack Unit: 1 to 5 tons (customizable)
• Per Shelf Level: 300 kg to 1500 kg (depending on design)
• System Total Load: Up to 40 tons per mobile base (or more based on design)

Dimensions

• Height: Up to 12 meters (customized as per warehouse height)
• Depth: Typically 600 mm to 1200 mm
• Length: Customizable depending on aisle length
• Aisle Width Required: As low as one operational aisle (1.2-1.5 m for manual, wider for forklifts)

Mobility Mechanism

• Rails: Precision-aligned steel rails embedded or surface-mounted

Drive Type:

• Manual (hand wheel)
• Mechanically Assisted (chain drive system)
• Motorized (PLC-controlled, remote-operated)

Movement Control (Motorized): Soft start/stop, anti-collision, overload sensors, emergency stop

Safety Features

• Emergency stop buttons
• Infrared or ultrasonic sensors (in motorized systems)
• Safety locks & mechanical stoppers
• Manual override in power failure
• Anti-tip and anti-derail mechanisms

Accessories & Add-ons

• Label holders / RFID tags
• Central locking mechanism
• LED lighting in aisles (motion-sensor-based)
• Fire detection and suppression integration
• Wire mesh backs / side panels
• Perforated panels (for ventilation)
