Drive in racking

Product Description

System Type

• Drive-In Racking (Single entry point)
• Drive-Through Racking (Access from both ends)

Structure Components

• Upright Frames
• Horizontal & Diagonal Bracings
• Top & Back Tie Beams
• Pallet Support Rails
• Entry Guides
• Stoppers (optional)

Materials Used

• High-quality cold-rolled steel
• Powder-coated or galvanized finish (for rust resistance)

Load Capacity

• Per pallet level: 500 kg - 1500 kg (can be customized)
• Per bay total: Depends on configuration; up to 10,000 kg+

Dimensions (customizable)

• Depth (Lanes): 2 - 10+ pallets deep
• Height: Up to 12 meters (based on MHE reach)
• Bay Width: Designed to fit standard pallet width + clearance (-1350 mm for 1200 mm wide pallet)
• Rail Height Increment: 75-100 mm typically

Pallet Type & Size

• Designed for standard pallets: 1200 x 1000 mm / 1200 x 800 mm
• Can be customized for non-standard pallets

Forklift Compatibility

• Requires counterbalance or reach trucks
• Aisle width typically between 3000 - 3500 mm (including entry guides)

Storage Mode

• LIFO (Last In First Out) for Drive-In
• FIFO (First In First Out) for Drive-Through

Safety Accessories

• Pallet stoppers
• Upright protectors
• Rail end stops
• Guide rails for forklift entry
• Load signs

Surface Finish

• Epoxy powder coating (standard indoor use)
• Hot-dip galvanization (for cold storage or outdoor applications)
