Cantilever Racking

Product Description

 Base:

• Anchored to the floor, supports the upright column.
• Made of heavy-duty steel for stability.

Uprights (Vertical Columns):

• Bear the load of the cantilever arms and stored materials.
• Perforated for adjustable arm placement.
• Heights typically range from 2 meters to 6 meters (customizable).

Arms (Cantilever Beams):

• Extend horizontally from uprights to hold the materials.
• Available in lengths from 600 mm to 1800 mm, depending on load.
• Adjustable in 50 mm to 100 mm pitch.

Bracing (Horizontal & Diagonal):

• Ensures the structural stability of the system.
• Galvanized or powder-coated finish for corrosion resistance.

Optional Accessories:

• End stops
• Roll-off protection
• Roofs (for outdoor applications)
• Decking (for mixed item storage)
• Height: 2000 mm - 6000 mm (or higher, custom)
• Arm Length: 600 mm - 1800 mm
• Arm Levels: 2 - 8 levels (depending on structure height)
• Column Spacing: 1000 mm - 1800 mm (based on load type)

Arm Load Capacity:

• Light Duty: up to 500 kg/arm
• Medium Duty: up to 1000 kg/arm
• Heavy Duty: up to 2500 kg/arm (or higher)

System Load Capacity:

• Designed to handle up to 10 tons per column (custom-engineered as needed)
• Material: High-grade cold-rolled or hot-rolled steel

Finish:

• Powder-coated (for indoor use)
• Hot-dip galvanized (for outdoor or corrosive environments)
